GS 500 ESSRBOND
Description:
ESSRBOND GS500 is a hydrophobic grout based on polyurethane. Upon contact with water, ESSRBOND GS500 reacts to closed cell rubber-like foam while expanding its volume up to 27 times. The cured material is of a constant volume. Since water is not a component of the foam structure, the cured material is essentially not affected by water or dryness. The reacted material does not shrink or swell. Depending on the pressure of injection, ESSRBOND GS500 reacts to a very dense material or foam.
FEATURES
- Negative side application possible
- Deep penetration into very small cracks
- Foam increases in volume to fill cavities and voids
- Excellent bond to surfaces
- Good adhesive strength, tolerant of movement
- Inert after curing, constant volume, no shrinkage
- Does not create new cracks
TECHNICAL PROPERTIES
| PROPERTIES | RESULTS |
| Form | Liquid Type |
| Color | Dark Brown |
| Solubility in Water | Hydrophobic |
| Density | 1.12 g/ml |
| Viscosity | 100-200 |
| Max. Expansion (25°C) | 2,700 % [Ratio 10:1 Resin: Water] |
| Induction Time (25°C) | 15 sec [Ratio 2:1 Resin: Water] |
| Gel Time (25°C) | 110 sec [Ratio 2:1 Resin: Water] |
| Tensile Shear Strength (23°C) | 4 N/mm² |
| Appearance | Light Yellow Polyurethane Foam |
| Corrosiveness | Non-Corrosive |
| Chemical Resistance | Resistant to most organic Solvent, Mild Acids, Alkali |
DOWNLOAD TECHNICAL DATA SHEET
APPLICATIONS
- Defective concrete (cracked or honeycombed)
- Concrete joints, Limestone, Brick construction
- Pipe intrusions, Wastewater tanks
- Tunnels, Dams, Subway (Metro), Sewers, Manholes, Utility boxes, etc.
- Soil stabilization
